Ecosolid

Ecosolid is an entry level solid tire option available in the 8” to 15” size range. Only available in standard black compound.

Kattintson a nagyobb képért

Méretek

METRIC SIZES

				Actual Dimensions [mm]		Load capacity [kg]
							Counterbalanced lift trucks up to 25 km/h		Other Vehicles
							Counterbalanced lift trucks up to 25 km/h		Other Vehicles
Size	Rim	Pattern	LOC	Width	O.D.	Static	Load	Steering Wheel	@ 6 km/h	@ 10 km/h	@ 25 km/h
Size	Rim	Pattern	LOC	Width	O.D.	Static	Wheel	Steering Wheel	@ 6 km/h	@ 10 km/h	@ 25 km/h
15x4½-8	3.00D-8	TR	●	103	372	1210	1040	800	1040	945	800
5.00-8	3.00D-8	TR	●	122	457	1645	1420	1090	1420	1290	1090
16x6-8	4.33R-8	TR	●	143	408	1735	1495	1150	1495	1360	1150
18x7-8	4.33R-8	TR	●	143	450	2490	2145	1650	2145	1950	1650
140/55-9	4,00E-09	TR	●	127	370	1360	1170	900	1170	1060	900
6.00-9	4,00E-09	TR	●	140	508	2190	1885	1450	1885	1710	1450
21x8-9	6,00E-09	TR	●	185	508	3200	2755	2120	2755	2500	2120
6.50-10	5.00F-10	TR	●	163	559	2720	2340	1800	2340	2125	1800
200/50-10	6.50F-10	TR	●	186	447	2870	2470	1900	2470	2240	1900
23x9-10	6.50F-10	TR	●	190	571	4000	3445	2650	3445	3125	2650
7.00-12	5.00S-12	TR	●	168	660	3380	2920	2240	2920	2645	2240
23x10-12	8.00G-12	TR	●	224	571	4380	3770	2900	3770	3420	2900
27x10-12	8.00G-12	TR	●	230	656	4530	3900	3000	3900	3540	3000
8.25-15	6.5-15	TR	●	206	787	5510	4750	3650	4750	4300	3650
28x9-15	7.0-15	TR	●	204	686	4000	3445	2650	3445	3125	2650
250-15	7.0-15	TR	●	216	704	5510	4745	3650	4745	4310	3650
300-15	8.0-15	TR	●	254	812	6795	5850	4500	5850	5310	4500
355/65-15	9.75-15	TR	●	278	809	9060	7800	6000	7800	7080	6000
